Accessing Service Mode Menus
Description The Service Mode menus are accessed by opening the door and pressing
the preselection buttons on the selection module.
The Service Mode will automatically start in the Total Counter menu. This
will be shown on the display.
Operation Buttons The four preselection buttons found at the top of the selection module are
used to access and activate the menus and their options.
Display The display shows which operation area the system is in and the value of
the setting. To simplify operation, the light above the buttons which can be
used light up.
Button function The buttons have the same function in all menus. The function of the se-
lection buttons:
Button Function
The indicated button is used as a "down" button. This but-
ton is used to move from one menu option to another and
from within a menu option to move from a menu category
to another (eg in the Total Counter menu to move from the
Total Counter to the Total Amount option).
The "clear" button is used as a "up" button. This button is
used to move to the previous menu option eg to move from
"Period 1 stop" to "Period 1 start".
The "clear" button is also used to move from the first menu
option to the last menu option (eg to move from "Rinse" to
"Rinse brewer" or to move from "Machine setting" to
"Happy hour disc.".
The indicated button is used as an "arrow" button, step-
ping to the right. This button is used to move from one
main menu to another and from a menu field to another
menu field within a menu option and from a menu option
back to a main menu (eg to move from the "Reset
Counters" menu to the "Reset +/-" menu and from the
"Reset +/-" menu back to the "Reset Counters" menu).
