Woodward LS-5 v2 Series User Manual

Brief Overview
1
2
3
4
5
6
7
A
1
2
3
4
5
6
7
B
Fig. 1: LS-5x2 Series (housing variants)
A LS-522 (plastic housing with display)
B LS-512 (sheet metal housing)
1
System A CT terminal
2 System A / System B PT terminal
3
Service port connector (USB/RS-232)
1
4 Relay outputs terminal
5 Discrete inputs terminal
6
CAN bus interface terminal
7 RS-485 interface terminal
1
Optional con󰈡guration cable for ToolKit con󰈡guration software and external extensions/
applications required:
• USB connector: DPC-USB direct con󰈡guration cable – P/N 5417-1251
• RS-232 connector: DPC-RS-232 direct con󰈡guration cable – P/N 5417-557
The LS-5 Series are circuit breaker control units for engine-generator system
management applications.
The control units can be used stand-alone or in applications in combination with
Woodward easYgen-3400/3500 genset control units.
3LS-5 v2 Series37650
Brief Overview
Released
