5.7 H: Terminal Functions
208 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
■ H6-07: Pulse Train Monitor Scaling
Pulse train monitor scaling sets the output frequency at terminal MP when the specified monitor item is at 100%. Set H6-
06 to 102 and H6-07 to 0 to make the pulse train monitor output synchronous to the output frequency.
■
H6-08: Pulse Train Input Minimum Frequency
Sets the minimum output frequency that can be detected by the pulse train input. Increasing this setting reduces the time
the drive needs to react to changes in the input signal.
• If the pulse input frequency falls below this level, the pulse input value will be 0.
• Enabled when H6-01 = 0, 1, or 2.
No. Name Setting Range Default
H6-07 Pulse Train Monitor Scaling 0 to 32000 Hz 1440 Hz
No. Name Setting Range Default
H6-08 Pulse Train Input Minimum Frequency 0.1 to 1000.0 Hz 0.5 Hz
SIEP_C710616_35.book 208 ページ ２０１５年１１月３０日 月曜日 午後２時２分
