5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 207
■ H6-01: Pulse Train Input Terminal RP Function Selection
Selects the function of pulse train input terminal RP.
Setting 0: Frequency reference
If the pulse input is set for this function and the frequency reference source is set to pulse input (b1-01, b1-15 = 4), the
drive reads the frequency value from terminal RP.
Setting 1: PI feedback value
Using this setting, the feedback value for PI control can be supplied as a pulse signal at terminal RP. Refer to b5: PI
Control on page 145 for details on PI control.
Setting 2: PI setpoint value
Using this setting, the setpoint value for PI control can be supplied as a pulse signal at terminal RP. Refer to b5: PI
Control on page 145 for details on PI control.
■
H6-02: Pulse Train Input Scaling
This parameter sets the pulse signal frequency that is equal to 100% of the input value selected in parameter H6-01.
■
H6-03: Pulse Train Input Gain
Sets the level of the input value selected in H6-01 when a pulse train signal with the frequency set in H6-02 is input to
terminal RP.
■
H6-04: Pulse Train Input Bias
Sets the level of the input value selected in H6-01 when no signal (0 Hz) is input to terminal RP.
■
H6-05: Pulse Train Input Filter Time
Sets the pulse train input filter time constant in seconds.
■
H6-06: Pulse Train Monitor Selection
Selects the monitor to output as a pulse train signal via terminal MP. Indicate which monitor to output entering the three
digits in U-. Refer to U: Monitor Parameters on page 253 for a complete list of monitors. Monitors that can be
selected by H6-06 appear in the table below.
No. Name Setting Range Default
H6-01 Pulse Train Input Terminal RP Function Selection 0 to 2 0
No. Name Setting Range Default
H6-02 Pulse Train Input Scaling 100 to 32000 Hz 1440 Hz
No. Name Setting Range Default
H6-03 Pulse Train Input Gain 0.0 to 1000.0% 100.0%
No. Name Setting Range Default
H6-04 Pulse Train Input Bias -100.0 to 100.0% 0.0%
No. Name Setting Range Default
H6-05 Pulse Train Input Filter Time 0.00 to 2.00 s 0.10 s
No. Name Setting Range Default
H6-06
<1> Set “000” when the terminal is not used, or when using the terminal in the through mode.
Pulse Train Monitor Selection
000
<1>, 031, 101, 102, 116, 501, 502,
801 to 809
102
SIEP_C710616_35.book 207 ページ ２０１５年１１月３０日 月曜日 午後２時２分
