C.9 MEMOBUS/Modbus Data Table
MEMOBUS/Modbus Communications
C
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 431
00D1H
CPF Contents 2
bit 0 Clock Fault (CPF16)
bit 1 Timing Fault (CPF17)
bit 2 Control Circuit Fault (CPF18)
bit 3 Control Circuit Fault (CPF19)
bit 4 Hardware fault at power up (CPF20)
bit 5 Hardware fault at communication start up (CPF21)
bit 6 A/D Conversion Fault (CPF22)
bit 7 PWM Feedback Fault (CPF23)
bit 8 Drive Unit Signal Fault (CPF24)
bit 9 Terminal board is not properly connected. (CPF25)
bit A ASIC BB Circuit Error (CPF26)
bit B ASIC PWM Setting Register Error (CPF27)
bit C ASIC PWM Pattern Error (CPF28)
bit D ASIC On-delay Error (CPF29)
bit E ASIC BBON Error (CPF30)
bit F ASIC Code Error (CPF31)
00D2H
bit 0 ASIC Start-up Error (CPF32)
bit 1 Watch-dog Error (CPF33)
bit 2 ASIC Power/Clock Error (CPF34)
bit 3 External A/D Converter Error (CPF35)
bit 4 to 7 Reserved
bit 8 Control Circuit Error (CPF40)
bit 9 Control Circuit Error (CPF41)
bit A Control Circuit Error (CPF42)
bit B Control Circuit Error (CPF43)
bit C Control Circuit Error (CPF44)
bit D Control Circuit Error (CPF45)
bit E, F Reserved
00D3H to 00D7H oFA0x Contents (CN5-A)
00D8H
oFA0x Contents (CN5-A)
bit 0 Option Compatibility Error (oFA00)
bit 1 Option not properly connected (oFA01)
bit 2 to 4 Reserved
bit 5 A/D Conversion Error (oFA05)
bit 6 Option Response Error (oFA06)
bit 7 to F Reserved
00D9H
oFA1x Contents (CN5-A)
bit 0 Option RAM Fault (oFA10)
bit 1 Option Operation Mode Fault (SLMOD) (oFA11)
bit 2 Drive Receive CRC Error (oFA12)
bit 3 Drive Receive Frame Error (oFA13)
bit 4 Drive Receive Abort Error (oFA14)
bit 5 Option Receive CRC Error (oFA15)
bit 6 Option Receive Frame Error (oFA16)
bit 7 Option Receive Abort Error (oFA17)
bit 8 to F Reserved
00DAH to 00DBH Reserved
00DBH
oFA3x Contents (CN5-A)
bit 0 Comm. ID Error (oFA30)
bit 1 Model Code Error (oFA31)
bit 2 Sumcheck Error (oFA32)
bit 3 Comm. option timeout waiting for response (oFA33)
bit 4 MEMOBUS Timeout (oFA34)
bit 5 Drive timeout waiting for response (oFA35)
bit 6 CI Check Error (oFA36)
bit 7 Drive timeout waiting for response (oFA37)
bit 8 Control Command Selection Error (oFA38)
bit 9 Drive timeout waiting for response (oFA39)
bit A Control Response Selection 1 Error (oFA40)
bit B Drive timeout waiting for response (oFA41)
bit C Control Response Selection 2 Error (oFA42)
bit D Control Response Selection Error (oFA43)
bit E, F Reserved
00DCH to 00FFH Reserved
<1> Units are determined by parameter o1-03.
<2> This value's number of decimal places depends on the drive model. The value will have two decimal places (0.01 A) if the drive model is
CIMR-E2A0004 to 2A0040, 4A0002 to 4A0023 and one decimal place (0.1 A) if the drive model is CIMR-E2A0056 to 2A0415, 4A0031
to 4A1200.
