C.9 MEMOBUS/Modbus Data Table
430 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
00C9H
Alarm contents 3
bit 0 to bit 1 Reserved
bit 2 Digital Operator Connection Fault (oPr)
bit 3 MEMOBUS/Modbus Communication Error (CE)
bit 4 Option Communication Error (bUS)
bit 5 Serial Communication Transmission Error (CALL)
bit 6 Motor Overload (oL1)
bit 7 Drive Overload (oL2)
bit 8 Reserved
bit 9 Option Card External fault (EF0)
bit A to bit B Reserved
bit C Serial Communication Transmission Error (CALL)
bit D Undertorque Detection 1 (UL3)
bit E Reserved
bit F MEMOBUS/Modbus Test Mode Fault (SE)
00CAH
Alarm contents 4
bit 0 Reserved
bit 1 Motor Overheat 1 (PTC Input) (oH3)
bit 2 to 5 Reserved
bit 6 PI Feedback Loss (FbL)
bit 7 PI Feedback Loss (FbH)
bit 9 Drive Disabled (dnE)
bit A to bit F Reserved
00CBH
Alarm Contents 5
bit 0 SI-T3 Watchdog Error (E5)
bit 1 SI-T3 Station Address Setting Error (AEr)
bit 2 SI-T3 Comm. Cycle Setting Error (CyC)
bit 3 High Current Alarm (HCA)
bit 4 Cooling Fan Maintenance Time (LT-1)
bit 5 Soft Charge Bypass Relay Maintenance Time (LT-2)
bit 6 Reserved
bit 7 SI-S EEPROM Error (EEP)
bit 8 External Fault 1 (input terminal S1) (EF1)
bit 9 External Fault 2 (input terminal S2) (EF2)
bit A to bit F Reserved
00CCH
Alarm Contents 6
bit 0 Output Voltage Detection Fault (VoF)
bit 1 IGBT Maintenance Time (90%) (TrPC)
bit 2 Capacitor Maintenance Time (LT-3)
bit 3 IGBT Maintenance Time (50%) (LT-4)
bit 4 Braking Transistor Overload Fault (boL)
bit 5 to 6 Reserved
bit 7 Motor Overheat (NTC Input) (oH5)
bit 8 DriveWorksEZ Alarm (dWAL)
bit 9 to B Reserved
bit C Thermistor Disconnect (THo)
bit D Underload Detection 6 (UL6)
bit E Waitting for RUN (WrUn)
bit F Reserved
00CDH to 00CFH Reserved
00D0H
CPF Contents 1
bit 0, 1 Reserved
bit 2 A/D Conversion Error (CPF02)
bit 3 PWM Data Fault (CPF03)
bit 4, 5 Reserved
bit 6 EEPROM Memory Data Error (CPF06)
bit 7 Terminal Board Connection Error (CPF07)
bit 8 EEPROM Serial Communications Fault (CPF08)
bit 9, A Reserved
bit B RAM Fault (CPF11)
bit C FLASH Memory Fault (CPF12)
bit D Watchdog Circuit Exception (CPF13)
bit E Control Circuit Fault (CPF14)
bit F Reserved
Register No. Contents
