YASKAWA E1000 User Manual

C.9 MEMOBUS/Modbus Data Table
MEMOBUS/Modbus Communications
C
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 429
00C2H
Fault contents 5
bit 0 MEMOBUS/Modbus Communication Error (CE)
bit 1 Option Communication Error (bUS)
bit 2 to bit 5 Reserved
bit 6 Option External Fault (EF0)
bit 7 PI Feedback Loss (FbL)
bit 8 Undertorque Detection 1 (UL3)
bit 9 Reserved
bit A High Slip Braking Overload (oL7)
bit B to E Reserved
bit F Hardware Fault (includes oFx)
00C3H
Fault contents 6
bit 0 to bit 4 Reserved
bit 5 Current Imbalance (LF2)
bit 6 Pullout Detection (STo)
bit 7 Reserved
bit 8 SI-T3 Watchdog Error (E5)
bit 9 Reserved
bit A Too many speed search restarts (SEr)
bit B to F Reserved
00C4H
Fault contents 7
bit 0 PI Feedback Loss (FbH)
bit 1 External Fault 1, input terminal S1 (EF1)
bit 2 External Fault 2, input terminal S2 (EF2)
bit 3 to bit 4 Reserved
bit 5 Current Offset Fault (CoF)
bit 6, 7 Reserved
bit 8 DriveWorksEZ Fault (dWFL)
bit 9 to bit B Reserved
bit C Output Voltage Detection Fault (voF)
bit D Braking Resistor Fault (rF)
bit E Braking Transistor Overload Fault (boL)
bit F Motor Overheat (NTC Input) (oH5)
00C5H
Fault contents 8
bit 0 Reserved
bit 1 Node Setup Fault (nSE)
bit 2 Thermistor Disconnect (THo)
bit 3 to 8 Reserved
bit 9 Underload Detection 6 (UL6)
bit A Polarity Judge Timeout (dv7)
bit B to D Reserved
bit E Power Unit Output Phase Loss 3 (LF3)
bit F Current Unbalance (UnbC)
00C6H
Fault contents 9
bit 0 Gate Drive Board Undervoltage (Uv4)
bit 1 to F Reserved
00C7H Reserved
00C8H
Alarm contents 2
bit 0 Undervoltage (Uv)
bit 1 Overvoltage (ov)
bit 2 Heatsink Overheat (oH)
bit 3 Drive Overheat (oH2)
bit 4 Overtorque 1 (oL3)
bit 5 Reserved
bit 6 Run Commands Input Error (EF)
bit 7 Drive Baseblock (bb)
bit 8 External Fault 3, input terminal S3 (EF3)
bit 9 External Fault 4, input terminal S4 (EF4)
bit A External Fault 5, input terminal S5 (EF5)
bit B External Fault 6, input terminal S6 (EF6)
bit C External Fault 7, input terminal S7 (EF7)
bit D External Fault 8, input terminal S8 (EF8)
bit E Cooling Fan Error (FAn)
bit F Reserved
Register No. Contents
