YASKAWA E1000 User Manual

C.9 MEMOBUS/Modbus Data Table
428 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
003EH
Output Frequency
r/min <4>
003FH 0.01% units
0040H to 004AH Used for various monitors U1-. Refer to U: Monitors on page 391 for parameter details.
004BH
Drive status (U1-12)
bit 0 During Run
bit 1 During Zero Speed
bit 2 During Reverse Run
bit 3 During Fault Reset Signal Input
bit 4 During Speed Agree
bit 5 Drive Ready
bit 6 Alarm
bit 7 Fault
bit 8 During Operation Error (oPE)
bit 9 During Momentary Power Loss
bit A to bit B Reserved
bit E ComRef status, NetRef status
bit F ComCtrl status, NetCtrl status
004CH to 007EH Used for various monitors U1-, U4-, U5- and U6-. Refer to U: Monitors on page 391 for parameter details.
007FH Alarm Code, Refer to Alarm Register Contents on page 433 for alarm codes.
0080H to 0097H
Used for monitors U2-, U3-. Refer to U: Monitors on page 391 for parameter details and Refer to Fault Trace Contents on page 432 for register
value descriptions.
0098H High Word of Accumulated Operation Time Monitor, 10H units (U4-01)
0099H Low Word of Accumulated Operation Time Monitor, 1H units (U4-01)
009AH High Word of Cooling Fan Operation Time Monitor (U4-03)
009BH Low Word of Cooling Fan Operation Time Monitor (U4-03)
009CH to 00AAH Reserved
00ABH Drive Rated Current <2>
00AEH, 00AFH Reserved
00B0H Option Code Connected to CN5-A
Communication Option: Register contains ASCII code of 1st and 3rd digit of the option card type number.
Example: Register value is 5343H for “SC” if a SI-C3 option card is installed.
00B1H–00B4H Reserved
00B5H
Frequency Reference After Soft-
starter (U1-16)
r/min units <4>
00B6H 0.01% units
00B7H
Frequency Reference
r/min <4>
00B8H 0.01% units
00B9H to 00BEH Reserved
00BFH Lists the last to digits of operation error code oPE.
00C0H
Fault contents 3
bit 1 Undervoltage (Uv1)
bit 2 Control Power Supply Undervoltage (Uv2)
bit 3 Soft Charge Circuit Fault (Uv3)
bit 4 IGBT Short Circuit (SC)
bit 5 Ground Fault (GF)
bit 6 Overcurrent (oC)
bit 7 Overvoltage (ov)
bit 8 Heatsink Overheat (oH)
bit 9 Heatsink Overheat (oH1)
bit A Motor Overload (oL1)
bit B Drive Overload (oL2)
bit C Overtorque Detection 1 (oL3)
bit D to F Reserved
00C1H
Fault contents 4
bit 0 External Fault at input terminal S3 (EF3)
bit 1 External Fault at input terminal S4 (EF4)
bit 2 External Fault at input terminal S5 (EF5)
bit 3 External Fault at input terminal S6 (EF6)
bit 4 External Fault at input terminal S7 (EF7)
bit 5 External Fault at input terminal S8 (EF8)
bit 6 Cooling Fan Error (FAn)
bit 7 to bit 9 Reserved
bit A Input Phase Loss (PF)
bit B Output Phase Loss (LF)
bit C Motor Overheat (PTC input) (oH3)
bit D Digital Operator Connection Fault (oPr)
bit E EEPROM Write Error (Err)
bit F Motor Overheat Fault (PTC input) (oH4)
Register No. Contents
SIEP_C710616_35.book 428 ページ ２０１５年１１月３０日 月曜日 午後２時２分
