D.3 UL Standards
454 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
Note: Model CIMR-E4A1200 is UL compliant when the air entering the drive-installed panel or cabinet is 45°C or less. For more
information, contact your nearest Yaskawa representative or our sales office.
■ Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors. Refer to national state or local codes for wiring. If external
power supply used, it shall be UL Listed Class 2 power source only or equivalent. Refer to NEC Article 725 Class 1,
Class 2, and Class 3 Remote-Control, Signaling, and Power Limited Circuits for requirements concerning class 1 circuit
conductors and class 2 power supplies.
Table D.8 Control Circuit Terminal Power Supply
2A0169 FWH-400A 400
2A0211 FWH-400A 400
2A0250 FWH-600A 600
2A0312 FWH-700A 700
2A0360 FWH-800A 800
2A0415 FWH-1000A 1000
Three-Phase 400 V Class
4A0002 FWH-40B 40
4A0004 FWH-50B 50
4A0005 FWH-70B 70
4A0007 FWH-70B 70
4A0009 FWH-90B 90
4A0011 FWH-90B 90
4A0018 FWH-80B 80
4A0023 FWH-100B 100
4A0031 FWH-125B 125
4A0038 FWH-200B 200
4A0044 FWH-250A 250
4A0058 FWH-250A 250
4A0072 FWH-250A 250
4A0088 FWH-250A 250
4A0103 FWH-250A 250
4A0139 FWH-350A 350
4A0165 FWH-400A 400
4A0208 FWH-500A 500
4A0250 FWH-600A 600
4A0296 FWH-700A 700
4A0362 FWH-800A 800
4A0414 FWH-800A 800
4A0515 FWH-1000A 1000
4A0675 FWH-1200A 1200
4A0930 FWH-1200A 1200
4A1200 FWH-1600A 1600
Input / Output Terminal Signal Power Supply Specifications
Multi-function digital outputs M1, M2, M3, M4, M5, M6 Requires class 2 power supply.
Multi-function digital inputs S1, S2, S3, S4, S5, S6, S7, S8, SC
Use the internal LVLC power supply of the drive. Use class 2 for external power supply.
Multi-function analog inputs +V, -V, A1, A2, A3, AC
Pulse train input RP, AC
Pulse train output MP, AC
Hardwire Base block inputs H1, H2, HC
Hardwire Base block monitor outputs DM+, DM- Requires class 2 power supply.
Model
CIMR-E
Fuse Type (Rated Voltage: 500 Vac)
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
