Agilent Technologies E6198B User Manual

6-1
Agilent TS-5000
E6198B Switch/Load Unit User Manual
Agilent Technologies
6
Using the Pin Matrix Cards
Using the 32-Pin Matrix Cards 6-2
Using the 64-Pin Matrix Cards 6-16
This chapter describes how to configure and use the Agilent Pin
Matrix Cards which slots into the Switch/Load unit.
Register descriptions for these cards are located in Appendix B
of this manual.
NOTE
This chapter describes using the Agilent 8792A or 8782A as the
Instrument Matrix. In some systems, the Agilent E6171B measurement
Control Module may be used as the Instrument Matrix. Refer to the
Agilent E6171B User's Manuals for more information.
