Using the Custom Card 7

E6198B Switch/Load Unit User Manual 7-7

J5 and J6 Connector Breakouts (32-Pin Matrix Cards)

32-Pin Matrix Card #1 can be cabled to J5 and 32-Pin Matrix

Card #2 can be cabled to J6. Figure 7-4 shows the J5 and J6

connector breakouts when cable part number E3751-61601 is

used to connect the 32-Pin Matrix Card(s) to J5 and J6.

Figure 7-5 J5 and J6 Breakouts (32-Pin Matrix Cards)

Aux32 (J6)

UUTCommon ( J 5)

J6J5

Note: Pinout for Aux and UUT Common connections is valid when

cable p/n E3751-61601 is used to connect to pin matrix cards.

Aux32 (J5)

UUTCommon ( J 6)

Aux1 (J6)

UUTCom (J5)

Aux1 (J5)

UUTCom (J6)

1122

64 64

To Pi n Matr i x #2To Pin Matrix #1

J5 Breakouts

J6 Breakouts
