Page #202 background image
A-2 E6198B Switch/Load Unit User Manual
A Switch/Load Unit And Card Specifications
Agilent E6198B Switch/Load Unit Specifications
Parameter Specification
Power Bus Resistance 0.02 Ω maximum
Power Bus Current 30 A maximum continuous
Peak Power Bus Current 40 A maximum (<0.1 second, duty cycle <10%)
Peak Power Bus Voltage 60 V maximum
Combined Power Bus Current (all buses) 60 A maximum continuous
Switch/Load Unit to Power Supply Cable
Resistance (per bus)
0.03
Ω (standard supplied Agilent cable with connectors
included)
Switch/Load Unit to Load Card Connection
Resistance
0.03
Ω maximum
Average Load Power for all loads mounted in
Switch/Load Unit
250 Watts average
500 Watts maximum
Maximum Current Consumption 30 A at 5 V
12.5 A at +12 V
1 A at -12 V
DAC Channels Vout: -16 V to +16 V
Iout: 10 mA
Resolution: 14 bit
Gain Error: .3% typical
Offset Error: 20 mV typical
