5-2 E6198B Switch/Load Unit User Manual
5 Using Load Cards and Loads
Load Card Capabilities
• The Agilent E6175A 8-Channel High Current Load Card, with
integral current sensing, is intended to be used with loads
mounted on the card. A 9-inch by 4-inch area of sheet metal
is open on the front of the card for mounting loads. The card
is two slots wide to allow mounting of larger loads.
• The Agilent E6176A 16-Channel High Current Load Card is a
single-slot design, requiring externally mounted loads. This
load card offers high load density for high current loads
where current transducers and bridge drive configuration
are not required.
• The Agilent E6177A 24-Channel Medium Current Load Card
(for non-inductive loads) is intended to be used with loads
mounted on the card. A 9-inch by 4-inch area of sheet metal
is open on the front of the card for mounting small loads.
This card is one slot wide and capable of up to 2A continuous
carry current.
Table 5-1 Load Card Capabilities
Function Agilent
E6175A
Agilent
E6176A
Agilent
E6177A
Agilent
U7177A
Agilent
E6178B
Agilent
N9377A
Agilent
N9378A
Agilent
N9379A
Number of
Channels
(Max.)
8 1624248 16 dual
load
24 quad
load
48 dual
load
Number of
Channels -
Unshared
relays
4 1624248 162448
Maximum
Current per
Channel
7.5A (15A
peak)
7.5A (15A
peak)
2 A 2A 30A 7.5A (15A
peak)
2A 2A
Current
Measuring
with Sense
Resistor
Yes Yes No Yes No Yes No No
Current
Measuring
with Current
Transducer
Yes No No No Yes No No No
Flyback
protection
available (User
Installed)
Yes Yes No No Yes Yes No No
To Next Page
