Switch/Load Unit and Plug-In Cards 3

E6198B Switch/Load Unit User Manual 3-9

E6198B Integrated Switch/Load Unit Description

The Agilent E6198B now comes as a system integrated unit or a

standalone unit. The features and functionality remains the

same as the previous E6198A. Differences between the two are

in the cabling and function selection panel.

Figure 3-6 E6198B Integrated SLU back view

Sense Bussed/Split

PB Sense Remote/Local

Frame Select
