Breakout Board Connector Name (for E6198B Standalone option)

Breakout board extends the connection from backplane to SLU

rear. Table 3-5 lists the description of each connector. .

Table 3-5 Breakout Board Connectors

Connector Description

J_1 Utility Connector (J102 extension connector)

J_3 Utility Connector (J102 internal connector)

J_5 Frame Select & Spare Supply (Connect to J1 of

backplane internal connector)

J_6 Power Bus Sense Local/Remote (Connect to J3 of

backplane internal connector)

J_7 Isense Bussed/Split (Connect to J2 of backplane

internal connector)

J_8 Spare Supply Connector

S1A-S1D Toggle switches for Local/Remote

S2A-S2H Toggle switches for Frame Select

S3A-S3F Toggle switches for Isense Bussed/Split

NOTE

The breakout board is not available with E6198B System Integrated

option. See Figure 3-6.
