Repair Information C

E6198B Switch/Load Unit User Manual C-7

Table C-2 Instrument Matrix Relays

Abus1 Abus2 Abus3 Abus4 UUT

Common

Inst1 K1101 K1201 K1301 K1401 K1001

Inst2 K1102 K1202 K1302 K1402 K1002

Inst3 K1103 K1203 K1303 K1403 K1003

Inst4 K1104 K1204 K1304 K1404 K1004

Inst5 K1105 K1205 K1305 K1405 K1005

Inst6 K1106 K1206 K1306 K1406 K1006

Inst7 K1107 K1207 K1307 K1407 K1007

Inst8 K1108 K1208 K1308 K1408 K1008

Inst9 K1109 K1209 K1309 K1409 K1009

Inst10 K1110 K1210 K1310 K1410 K1010

Inst11 K1111 K1211 K1311 K1411 K1011

Inst12 K1112 K1212 K1312 K1412 K1012

Inst13 K1113 K1213 K1313 K1413 K1013

Inst14 K1114 K1214 K1314 K1414 K1014

Inst15 K1115 K1215 K1315 K1415 K1015

Inst16 K1116 K1216 K1316 K1416 K1016

Table C-3 Bypass and Disconnect Relays

Abus1 Abus2 Abus3 Abus4

Bypass Relays K2 K4 K6 K8

Disconnect Relays K1 K3 K5 K7

Table C-4 Miscellaneous Relays

Inst2 to System Ground Relay K502

DAC1 to Inst1 K503

DAC2 to Inst1 K504
