A-4 E6198B Switch/Load Unit User Manual
A Switch/Load Unit And Card Specifications
Agilent E6176A 16-Channel High-Current Load Card Specifications
Parameter Specification
Path resistance from power bus to load card
connect
0.4 Ω maximum
Exclusive of load, with standard 0.05 Ω sense resistor
and 10 A slo-blo fuse installed. (5 Ω for load currents <
1 A.)
Load path relay operate/release time 10/8 msec typical, 16/10 msec maximum, 30 cps max
Peak voltage to Earth 60 V continuous
500 V maximum transient, non-switching (delays to
<60V in 200 mS)
Load carry/switching current 7.5 A maximum non-switching, continuous
Load carry peak current 15 A max., non-switching (<100 msec, <2% duty cycle)
Load switching power 150 Watts maximum, resistive load
Load switching voltage 60 V maximum
Minimum permissible load 1 mA, 1V
Basic current sense accuracy with standard
0.05Ω sense resistor
0.1 % maximum
Maximum Current Consumption 0.6 A at 5 V
0.7 A at 12 V
