3-20 E6198B Switch/Load Unit User Manual

3 Switch/Load Unit and Plug-In Cards

T1-T14 SLU Logic Power Supply Connector

T1-T14 provides the required +5 volts and ±12 volts for

powering the backplane and Load Cards. Table 3-10 shows each

jumpers contains difference power supply.

Table 3-10 Power Supply Input for each Jumpers

Jumper Input Voltage

T1 +5V

T2 +5V

T3 +5V

T4 -12V

T5 +12V

T6 +12V

T7 +12V

T8 GND

T9 GND

T10 GND

T11 GND

T12 GND

T13 GND

T14 GND
