A-6 E6198B Switch/Load Unit User Manual

A Switch/Load Unit And Card Specifications

Agilent U7177A 24-Channel Medium-Current Load Card Specifications

Parameter Specification

Path resistance from power bus to load card

connect

0.5

Ω maximum

Load path relay operate/release time 3.3/2.4 msec typical

8/8 msec max,

10 cps maximum

Peak Voltage to Earth 60 V continuous

500 V maximum transient, non-switching (delays to

<60V in 200 mS)

Load carry/switching current 2 A maximum

Relay switching voltage

60 Vdc maximum

Minimum permisissible load 10 μΑ

10 mV DC

Basic current sense accuracy with standard 0.05 Ω

sense resistor

0.1% maximum

* Exclusive of load, with standard 0.05Ω sense resistor and 10A slo-blo fuse installed. (5Ω for load currents <0.1A.)
