Switch/Load Unit And Card Specifications A
E6198B Switch/Load Unit User Manual A-11
Agilent E8792A and E8793A Specifications
Instrument Multiplexer (Agilent E8792A Only)
General Specifications (Agilent E8792A and E8793A)
Parameter Specification
Number of Analog Instrument Channels 16
Analog Channel Voltage (Max.): 200 volts
Resistance: <1
Ω
Unbalanced Bandwidth: 10 MHz (Minimum)
Balanced Pair Bandwidth: 5 MHz (Minimum)
Parameter Specification
Power Requirements Voltage:+5 Vdc
Capacitance - DUT pin to UUT Common Open channel:100 pF
Closed channel:300 pF
Resistance DUT pin to auxiliary input:1
Ω (Max.)
DUT pin to analog bus connector:1
Ω* (Max.)
* with 200
Ω protection resistor bypassed.
Pin channel voltage 200 volts
No. of concurrent analog channels 4
Operating temperature 0 to 40°C
Operating humidity 80% Relative Humidity, 0 to 40°C
Maximum Current Consumption 2.9 A at 5 V for E8792A
2 A at 5 V for E8793A
