Switch/Load Unit and Plug-In Cards 3

E6198B Switch/Load Unit User Manual 3-11

The breakout panel is available with the E6198B Standalone

option and is easily accessible from the SLU rear.

Figure 3-8 shows connector locations on the breakout board

(external board). Refer Table 3-5 for the detailed

descriptions.

Figure 3-8 Switch/Load Unit Breakout Board Connectors (Standalone only)

BREAKOUT BOARD (External Board)

BACK

J_5

J_6

J_7

J_3

FRONT

J_1

J_8

S3A-S3F

S1A-S1D

S2A-S2H
