Using the Custom Card 7
E6198B Switch/Load Unit User Manual 7-3
Figure 7-1 Custom Card Features
Register Decoding Circuitry
Breadboard Area
J5 and J6 route Aux
channels from 32-Pin
Matrix #1 and #2
or general purpuse
breakout input
J3 and J4 route DAC
and/or Event Detector lines
96-Pin DIN C connector
Routes Config Lines to
Test System Interface
96-Pin DIN C connector
(to backplane)
Brings +/-12 V, Data Address
and Control Lines onto the
Custom Card
Wire-wrap breakout area.
DI, DO & +/- 12 Volts
32 Configuration lines
2 x 32 Aux channelsDAC or Event Detector (if present)
J3
J4
J5 J6
J2
J1
J55 J56
J53 J54
J50
J52
