Switch/Load Unit And Card Specifications A

E6198B Switch/Load Unit User Manual A-5

Agilent E6177A 24-Channel Medium-Current Load Card Specifications

Parameter Specification

Path resistance from power bus to load card

connect

0.5 Ω maximum

Exclusive of load, with standard 0.05

Ω sense resistor

and 10 A slo-blo fuse installed. (5

Ω for load currents

<0.1 A.)

Load path relay operate/release time 3.3/2.4 msec typical, 8/8 msec max, 10 cps maximum

Peak voltage to Earth 60 V continuous

500 V maximum transient, non-switching (delays to

<60V in 200 mS)

Load carry/switching current 2 A maximum

Relay switching voltage 60 Vdc maximum

Minimum permissible load 10 uA, 10 mV DC

Maximum Current Consumption 2.2 A at 5 V
