Switch/Load Unit And Card Specifications A

E6198B Switch/Load Unit User Manual A-13

Agilent E8782A and E8783A Specifications

Instrument Multiplexer (Agilent E8782A Only)

General Specifications (Agilent E8782A and E8783A)

Parameter Specification

Number of Analog Instrument Channels 24

Analog Channel Voltage (Max.):200 volts

Resistance:< 1Ω

Unbalanced Pair Bandwidth:10MHz (Minimum)

Balanced Pair Bandwidth:5MHz (Minimum)

Parameter Specification

Power Requirements Voltage:+5 Vdc

Capacitance – DUT pin to UUT Common Open channel:100 pF

Closed channel:300 pF

Resistance DUT pin to auxiliary input:1 Ω (Max.)

DUT pin to analog bus connector: 1Ω* (Max.)

* with 200 Ω protection resistor bypassed.

Pin channel voltage 200 volts

No. of concurrent analog channels 4

Operating temperature 0 to 40

Operating humidity 80% Relative Humidity, 0 to 40

Maximum Current Consumption 3 A at 5 V
