Agilent Technologies E6198B User Manual

Using the Pin Matrix Cards 6
E6198B Switch/Load Unit User Manual 6-25
Figure 6-16 J2 Pinouts--Rear Aux Access for E8782A
Row a b c d e
32 Aux1 UUT Common System Ground UUT Common AUX 33
31 Aux2 UUT Common System Ground UUT Common AUX 34
30 Aux3 UUT Common System Ground UUT Common AUX 35
29 Aux4 UUT Common System Ground UUT Common AUX 36
28 Aux5 UUT Common System Ground UUT Common AUX 37
27 Aux6 UUT Common System Ground UUT Common AUX 38
26 Aux7 UUT Common System Ground UUT Common AUX 39
25 Aux8 UUT Common System Ground UUT Common AUX 40
24 Aux9 UUT Common System Ground NC NC
23 Aux10 UUT Common System Ground NC NC
22 Aux11 UUT Common System Ground NC NC
21 Aux12 UUT Common System Ground NC NC
20 Aux13 UUT Common System Ground NC NC
19 Aux14 UUT Common System Ground NC NC
18 Aux15 UUT Common System Ground NC NC
17 Aux16 UUT Common System Ground NC NC
16 Aux17 UUT Common System Ground NC NC
15 Aux18 UUT Common System Ground NC NC
14 Aux19 UUT Common System Ground NC NC
13 Aux20 UUT Common System Ground NC NC
12 Aux21 UUT Common System Ground NC NC
11 Aux22 UUT Common System Ground NC NC
10 Aux23 UUT Common System Ground NC NC
9 Aux24 UUT Common System Ground NC NC
8 Aux25 UUT Common System Ground NC NC
7 Aux26 UUT Common System Ground NC NC
6 Aux27 UUT Common System Ground NC NC
5 Aux28 UUT Common System Ground NC NC
4 Aux29 UUT Common System Ground NC NC
3 Aux30 UUT Common System Ground NC NC
2 Aux31 UUT Common System Ground NC NC
1 Aux32 UUT Common System Ground NC NC
