Configuring the Switch/Load Unit 4

E6198B Switch/Load Unit User Manual 4-11

For system integrated SLU, jumpers are used to select between

Bussed/Split, see Figure 4-12.

Figure 4-12 ISense Bussed/Split Interface (Integrated SLU)

NOTE

Ensure Load Cards that will be accessed simultaneously for current-sense

readings are located in slots that do not share a common current-sense

bus.
