Agilent Technologies E6198B

Register Definitions B
E6198B Switch/Load Unit User Manual B-13
Current Sense Select (W) Base + 3
h
This register controls the current sense relays of the card.
Since only one current sense channel at a time per slot is
allowed, these channel selects are encoded. This allows for
either none or one current sense relay to be selected. Writing to
this register starts the reed relay timer.
• Write Only
• Undefined bits are not used.
• Select: 001
2
- 100
2
valid selects, 000
2
or 101
2
- 111
2
unselected
001
2
- corresponds to current sense select on channels 1 and
2.
010
2
- corresponds to current sense select on channels 3 and
4.
011
2
- corresponds to current sense select on channels 5 and
6.
100
2
- corresponds to current sense select on channels 7 and
8.
000
2
or nnn
2
>100
2
- means no current sense relay selected
(Example: Setting the current sense register to 1002 selects
the fourth pair of channels, channels 7 and 8. Therefore
relays K7 and K8 would be closed.)
• Power On/Reset State = 0
Bit 7-3 2-0
Purpose
Undefined I Sense Select
Setting X Channel #'s
Select Value 0,5-7 1 (001) 2 (010) 3 (011) 4 (100)
Relays
none K1, K2 K3, K4 K5, K6 K7, K8
Channels None 1, 2 3, 4 5, 6 7, 8
