Register Definitions B
E6198B Switch/Load Unit User Manual B-21
• State: 1 = closed, 0 = open
• Power On/Reset State = 0
Load Select 17-24 (W) Base + 5
h
This register controls the Load Select switch armature relays for
channels 17-24. The register uses positive logic: 1 = closed.
Writing to this register starts the relay timer.
• Write Only
• State: 1 = closed, 0 = open
• Power On/Reset State = 0
Power Select 1-8 (W) Base + 6
h
This register controls the Pull Up/Down Power Select armature
relays for channels 1-8. These relays are Form C and the register
uses positive logic: 1 = NO shorted to COM, NC is open; 0 = NC
shorted to COM, NO is open. The power buses selected are
determined by how the card is configured. Writing to this
register starts the relay timer.
• Write Only
• State: 1 = NO shorted to COM, NC is open; 0 = NC shorted to
COM, NO is open
• Power On/Reset State = 0
Bit 76543210
Purpose
K48
CH 24
K46
CH 23
K44
CH 22
K42
CH 21
K40
CH 20
K38
CH 19
K36
CH 18
K34
CH 17
Setting statestatestatestatestatestatestatestate
Bit 76543 210
Purpose
K15
CH 8
K13
CH 7
K11
CH 6
K9
CH 5
K7
CH 4
K5
CH 3
K3
CH 2
K1
CH 1
Setting state state state state state state state state
