Register Definitions B
E6198B Switch/Load Unit User Manual B-25
(Example: Setting the current sense register to 0001102
selects channel six. Therefore relays K59 and K60 would be
closed.)
• Power On/Reset State = 0
Load Select 1-8 (W) Base + 4h
This register controls the Load Select switch armature relays for
channels 1- 8. The register uses positive logic: 1 = closed.
Writing to this register starts the armature relay timer.
• Write Only
• State: 1 = closed, 0 = open
• Power On/Reset State = 0
Load Select 9-16 (W) Base + 5h
This register controls the Load Select switch armature relays for
channels 9-16. The register uses positive logic: 1 = closed.
Writing to this register starts the relay timer.
Select 0,
25-63
123456789101112
Relays
None K49,
K50
K51,
K52
K53,
K54
K55,
K56
K57,
K58
K59,
K60
K61,
K62
K63,
K64
K65,
K66
K67,
K68
K69,
K70
K71,
K72
Select 13 14 15 16 17 18 19 20 21 22 23 24
Relays
K73,
K74
K75,
K76
K77,
K78
K79,
K80
K81,
K82
K83,
K84
K85,
K86
K87,
K88
K89,
K90
K91,
K92
K93,
K94
K95,
K96
Bit76543210
Purpose
K32
CH8
K31
CH7
K30
CH6
K29
CH5
K28
CH4
K27
CH3
K26
CH2
K25
CH1
Setting statestatestatestatestatestatestatestate
