Register Definitions B
E6198B Switch/Load Unit User Manual B-27
• Write Only
• State: 1 = NO shorted to COM, NC is open; 0 = NC shorted to
OM, NO is open
• Power On/Reset State = 0
Power Select 9-16 (W) Base + 8h
This register controls the Pull Up/Down Power Select armature
relays for channels 9-16. These relays are Form C and the
register uses positive logic: 1 = NO shorted to COM, NC is open;
0 = NC shorted to COM, NO is open. The power buses selected
are determined by how the card is configured. Writing to this
register starts the relay timer.
• Write Only
• State: 1 = NO shorted to COM, NC is open; 0 = NC shorted to
COM, NO is open
• Power On/Reset State = 0
Power Select 17-24 (W) Base + 9h
This register controls the Pull Up/Down Power Select armature
relays for channels 17-24. These relays are Form C and the
register uses positive logic: 1 = NO shorted to COM, NC is open;
0 = NC shorted to COM, NO is open. The power buses selected
are determined by how the card is configured. Writing to this
register starts the relay timer.
Bit76543210
Purpose
K16
CH16
K15
CH15
K14
CH14
K13
CH13
K12
CH12
K11
CH11
K10
CH10
K9
CH9
Setting statestatestatestatestatestatestatestate
Bit76543210
Purpose
K24
CH24
K23
CH23
K22
CH22
K21
CH21
K20
CH20
K19
CH19
K18
CH18
K17
CH17
Setting statestatestatestatestatestatestatestate
