Register Definitions B
E6198B Switch/Load Unit User Manual B-45
shorted to COM, NO is open. The power buses selected are
determined by how the card is configured. Writing to this
register starts the relay timer.
• Write Only
• State: 1 = NO, shorted to Pwr node
• State: 0 = NC, shorted to Pwr node
• Power On/Reset State = 0 (all channels connected to NC)
Power Select 9-16 (W) Base + 13
h
This register controls the Pull Up/Down Power Select armature
relays for channels 9-16. These relays are Form C and the
register uses positive logic: 1 = NO shorted to COM, NC is open;
0 = NC shorted to COM, NO is open. The power buses selected
are determined by how the card is configured. Writing to this
register starts the relay timer.
• Write Only
• State: 1 = NO, shorted to Pwr node
• State: 0 = NC, shorted to Pwr node
• Power On/Reset State = 0 (all channels connected to NC)
Power Select 17-24 (W) Base + 14
h
This register controls the Pull Up/Down Power Select armature
relays for channels 17-24. These relays are Form C and the
register uses positive logic: 1 = NO shorted to COM, NC is open;
Bit 76543 210
Purpose
Pwr8 Pwr7 Pwr6 Pwr5 Pwr4 Pwr3 Pwr2 Pwr1
Setting state state state state state state state state
Bit 76543 210
Purpose
Pwr16 Pwr15 Pwr14 Pwr13 Pwr12 Pwr11 Pwr10 Pwr9
Setting state state state state state state state state
