E6198B Switch/Load Unit User Manual B-51

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 9-12 (W) Base + 8

This register controls the power selection relays for channels 9

through 12 with two possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 13-16 (W) Base + 9

This register controls the power selection relays for channels 13

through 16 with two possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Bit 76543 210

Purpose

Chan12.2 Chan12.1 Chan11.2 Chan11.1 Chan10.2 Chan10.1 Chan9.2 Chan9.1

Setting state state state state state state state state

Bit 76543 210

Purpose

Chan16.2 Chan16.1 Chan15.2 Chan15.1 Chan14.2 Chan14.1 Chan13.2 Chan13.1

Setting state state state state state state state state
