B-56 E6198B Switch/Load Unit User Manual
B Register Definitions
• State: 1 = NO, shorted to Pwr node
• State: 0 = NC, shorted to Pwr node
• Power On/Reset State = 0 (all channels connected to NC)
Power Select 33-48 (W) Base + 14
h
This register controls the Pull Up/Down Power Select armature
relays for channels 33-48. Each bit controls power shared by two
channels. These relays are Form C and the register uses positive
logic: 1 = NO shorted to COM, NC is open; 0 = NC shorted to
COM, NO is open. The power buses selected are determined by
how the card is configured. Writing to this register starts the
relay timer.
• Write Only
• State: 1 = NO, shorted to Pwr node
• State: 0 = NC, shorted to Pwr node
• Power On/Reset State = 0 (all channels connected to NC)
Bit 76543 210
Purpose
Pwr47-48 Pwr45-46 Pwr43-44 Pwr41-42 Pwr39-40 Pwr37-38 Pwr35-36 Pwr33-34
Setting state state state state state state state state
