Agilent Technologies E6198B User Manual

B-76 E6198B Switch/Load Unit User Manual
B Register Definitions
Not Used Base + 5
h
Register offser 5h used only for placeholder to make software
addressing simpler.
Aux Relays
Not available for Measurement matrix card without auxiliary
Auxilary Relay 1-8 (W)
Base + 6
h
Auxilary Relay 9-16 (W)
Base + 7
h
Auxilary Relay 17-24 (W)
Base + 8
h
Auxilary Relay 25-32 (W)
Base + 9
h
Auxilary Relay 33-40 (W)
Base + A
h
(10
10
)
Bits76543210
Write
Aux
8
Aux
7
Aux
6
Aux
5
Aux
4
Aux
3
Aux
2
Aux
1
Bits76543210
Write
Aux
16
Aux
15
Aux
14
Aux
13
Aux
12
Aux
11
Aux
10
Aux
9
Bits76543210
Write
Aux
24
Aux
23
Aux
22
Aux
21
Aux
20
Aux
19
Aux
18
Aux
17
Bits76543210
Write
Aux
32
Aux
31
Aux
30
Aux
29
Aux
28
Aux
27
Aux
26
Aux
25
Bits76543210
Write
Aux
40
Aux
39
Aux
38
Aux
37
Aux
36
Aux
35
Aux
34
Aux
33
