9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-3-11
Ethernet Capacity and RF Channel Bandwidths
Table 3-3 and Table 3-4 summarize ETSI and ANSI RF channel bandwidth
options for Ethernet capacity assignments from 40 to 300 Mbps. Nominal
Ethernet capacities are used.
With the RAC 40 CCDP XPIC cards, two links are operated on the same
frequency channel, one using the vertical polarization, the other the horizontal.
Table 3-3. Bandwidth, Modulation and RAC Type: ETSI
Ethernet
Capacity Mbps
RF Ch.
Bandwidth MHz
Modulation RAC
40 14 16 QAM RAC 30
40 28 QPSK RAC 30
65 14 64 QAM RAC 30
80 28 16 QAM RAC 30
100 28 32 QAM RAC 30
130 28 64 QAM RAC 30
RAC 40
130 56 16 QAM RAC 3X
150 28 128 QAM RAC 30
RAC 3X
RAC 40
150 40 64 QAM RAC 3X
150 56 16 QAM RAC 3X
190 28 256 QAM RAC 3X
200 56 64 QAM RAC 3X
300 56 128 QAM RAC 3X
