Chapter 3. 9500 MXC Nodes
Vol. II-3-12 Alcatel-Lucent
Table 3-4. Bandwidth, Modulation and RAC Type: ANSI
More Information
For DAC ES, refer to DAC ES on page 3-45
For DAC GE, refer to DAC GE on page 3-53
For RAC 30/3X, refer to RAC 30V3, RAC 3X on page 3-22.
For RAC 40, refer to RAC 40 on page 3-28.
Ethernet
Capacity Mbps
RF Ch.
Bandwidth MHz
Modulation RAC
40 10 64 RAC 30
40 20 16 RAC 30
40 30 QPSK RAC 30
50 20 16 RAC 30
50 40 RAC 3X
85 30 32 RAC 30
105 20 128 RAC 30
105 30 32 RAC 30
RAC 40
105 40 16 RAC 3X
130 30 64 RAC 30
130 40 32 RAC 3X
130 50 16 RAC 3X
150 30 MHz 128 QAM RAC 30
RAC 3X
RAC 40
150 40 MHz 64 QAM RAC 3X
150 40 MHz 32 QAM RAC 3X
150 50 MHz 16 QAM RAC 3X
300 50 MHz 256 QAM RAC 3X
