Table 3-9. RAC ANSI Common Carrier System Options
Capacity Modulation Channel Bandwidth RAC 30V3 RAC 3X
4xDS1 QPSK 5 MHz X
8xDS1 QPSK 10 MHz X
8xDS1 16 QAM 5 MHz X
8xDS1 32 QAM 3.75 MHz X
16xDS1 QPSK 20 MHz X
16xDS1 16 QAM 10 MHz X
16xDS1 128 QAM 5 MHz X
28xDS1 QPSK 30 MHz X
28xDS1 16 QAM 20 MHz X
28xDS1 64 QAM 10 MHz X
32xDS1 QPSK 40 MHz X
32xDS1 16 QAM 20 MHz X
70xDS1 16 QAM 40 MHz X
70xDS1 32 QAM 30 MHz X
84xDS1 16 QAM 50 MHz X
84xDS1 32 QAM 40 MHz X
84xDS1 64 QAM 30 MHz X
100xDS1 16 QAM 50 MHz X
100xDS1 32 QAM 40 MHz X
100xDS1 128 QAM 30 MHz X
1xDS3 QPSK 30 MHz X
1xDS3 64 QAM 10 MHz X
3xDS3 32 QAM 40 MHz X
3xDS3 64 QAM 30 MHz X
4xDS3 64 QAM 40 MHz X
4xDS3 256 QAM 30 MHz X
