Chapter 3. 9500 MXC Nodes
Vol. II-3-26 Alcatel-Lucent
Please check the Product Release Notes to confirm the availability of modem profiles.
Typical Link Delay Times
The delay times listed in the following tables reflect typical one-way link delays.
Table 3-10. Link Delay Times for RAC 30V3: ETSI Rates
Table 3-11. Link Delay Times for RAC 3X: ETSI Rates
1xOC3 16 QAM 50 MHz X
1xOC3 64 QAM 40 MHz X
1xOC3 128 QAM 30 MHz X X
2xOC3 256 QAM 50 MHz X
Capacity Modulation Channel Bandwidth RAC 30V3 RAC 3X
RAC 30V3 ms
5E1,7M,QPSK 1.1
10E1,14M,QPSK 0.63
10E1,7M,16Q 0.63
20E1,28M,QPSK 0.41
20E1,14M,16Q 0.42
40E1,28M,16Q 0.3
52E1,28M,32Q 0.27
64E1,28M,64Q 0.26
75E1,28M,128Q 0.25
1STM1,28M,128Q 0.13
RAC3X ms
64E1,56M,16Q 0.34
75E1,56M,16Q 0.31
1STM1,56M,16Q 0.19
1STM1,40M,64Q 0.19
1STM1,28M,128Q 0.19
