Chapter 3. 9500 MXC Nodes
Vol. II-3-52 Alcatel-Lucent
Green Normal operation
Orange flashing Configuration not supported, or software / hardware
incompatible
1
Red Critical alarm
2
3 RJ-45 Port
Connector
Assembly
Four RJ-45 connectors labelled Ports 1 to 4 provide 10/100Base-T access to customer
networks. Internally, the interface implements an ethernet bridging/switching function.
Each RJ-45 port connector includes Activity and Connection LEDs:
Ethernet orange
LED
Orange flashing LED indicates Ethernet receive activity. Off indicates no receive
activity.
Ethernet green
LED
Green LED indicates connection of an Ethernet link. Off indicates no Ethernet link
connection.
1. Includes situations where the slot configuration does not support the plug-in, or the plug-in requires a later/different version of
system software.
2. Indicates a traffic-affecting hardware failure.
No Item/Label Description
