9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. III-2-3
Figure 2-1. ODU and Mounting Collar
Figure 2-2 shows the ODU mounting collar, pole mount and polarization rotator
for an Andrew antenna.
Figure 2-2. Andrew Pole Mount and ODU Mounting Collar
Figure 2-3 shows the ODU mounting collar, pole mount, and polarization rotator
