9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. III-2-35
12. Check the positioning of the bracket, carefully adjusting the assembly if
necessary, and tighten all nuts.
13. Loop and secure the ground wire before hoisting the ODU into position.
14. Attach the terminated ODU cable to the suppressor and firmly hand tighten.
Ensure the cable is first formed (bent to fit) before it is attached to the
suppressor. If necessary fit a right angle connector to ease the running of the
ODU cable from the suppressor.
Do not attach the ODU cable to the suppressor and then use this as a levering
point to bend the ODU cable. Always bend the ODU cable to fit onto the
suppressor before attaching it to the suppressor.
