9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-2-13
Installing Dial-up Connection for Serial COM port: Windows 2000 & 98
The 9500 MXC modem driver must first be installed.
To configure the dial-up connection:
1. From the PC Control Panel, select
Network and Dial-Up Connections >
Make New Connection.
The Network Connection Wizard window is displayed.
2. Click
Next.
3. Select
Dial up to private network and click Next.
4. Select
Modem - 9500 MXC V.24 Modem [38400 bps] and click Next.
5. Enter a number in the phone number box (any number) and click
Next.
6. Type the name you want to use for this connection.
7. Select the
Add a short cut to my desktop option.
8. To complete the installation, click
Finish.
To check setup and operation, refer to the topic Starting 9500 MXC CT on
page 2-19.
Installing a Dial-up Connection for Serial COM Port: Windows XP
This procedure sets an Internet dial-up connection. The 9500 MXC modem
driver must first be installed.
To configure the connection:
1. From the PC Control Panel, select
Network Connections > Create a new
connection
. The New Connection Wizard is displayed.
2. Click
Next.
3. Select Connect to the Internet.
4. Select Setup my connection manually.
5. Select Connect using a dial up modem.
6. Select 9500 MXC V.24 Modem 38400bps.
7. Type in an ISP Name or a name for the connection, such as 9500 MXC.
8. Enter any phone number, such as 1234567 (the dial up connection may not
work if the phone number is left blank).
9. Select Anyone’s use.
If the 9500 MXC V.24 Modem is the only modem installed, it is automatically
assigned to the new network connection.
