Chapter 2. Setting Up 9500 MXC CT
Vol. IV-2-14 Alcatel-Lucent
10. Leave the Username and Password blank and click Next.
11. Click on Add a shortcut to this connection to the desktop.
12. Click Finish.
To check setup and operation, refer to Starting 9500 MXC CT on page 2-19.
Installing a COM Port Communications Cable Connection: Windows XP
This procedure sets up a communications-cable connection between your CT PC
and 9500 MXC. There is no need to first install the 9500 MXC modem driver.
To configure the connection:
1. From the PC Control Panel, select
Network Connections > Create a new
connection
.
The New Connection Wizard is displayed.
2. Click
Next.
3. Select
Set up an advanced connection and click Next.
4. Select Connect directly to another computer and click Next.
5. Select Guest and click Next.
6.
Enter a computer name, such as 9500 MXC, and click Next.
7. Select a COM port, such as COM1, and click Next.
8. Select Anyone’s use and click Next.
9. Click add a shortcut to place a shortcut on your desktop, and click Finish to
complete.
10. The Connect 9500 MXC window is presented. Ignore the User name and
Password fields and click Properties.
11. Under General, the Select a device field displays the configured COM port
and parallel port options. Select Communications cable between two
computers (COM1)
1
and click Configure.
12. In the Maximum speed (bps) field, use the drop-down menu to select 38400.
Under Hardware features check the default settings, which should only
indicate a tick in Enable hardware flow control.
Ensure the COM port selected has not been configured to share dial-up drivers
for other devices. If an existing modem driver is configured on the COM port, this
communications cable procedure will not operate. Where a conflict exists,
remove the competing drivers.
1
The COM port number will be the number selected in step 7.
