9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-2-17
3. Change the COM port number in the drop box to the desired selection.
4. Click
OK and OK to return to the Device Manager window.
5. Close the Device Manager and click
OK to close the System Properties
window.
This completes installation of the USB adaptor and confirmation of its COM
port.
Next Step
Installing the V.24 Modem Driver for USB on page 2-17.
Installing the V.24 Modem Driver for USB
To install the V.24 modem driver:
1. Select
Start > Settings > Control Panel.
2. Select
Phone and Modem Options > Modems > Add.
3. In the Add Hardware window, select
Don’t detect my modem; I will select
it from a list
. Click Next.
4. Select
Have Disk and browse to the 9500 MXC Installation Kit CD to select
the 9500 MXC V.24 Modem Driver.inf file. Click
Open.
5. In the Install from disk window, select the CDROM drive and click
OK.
6. If a prompt appears saying ‘This driver is not digitally signed’, ignore and
click
Next.
7. For a USB serial adaptor you must select the same COM port assignment as
determined in Installing the USB-to-Serial Adapter on page 2-16, and click
Next.
8. For a USB adaptor installation a warning message may state that the particular
driver has not passed Windows Logo testing to ensure Windows XP
compatibility. Ignore and click
Continue anyway.
9. Click
Finish, then OK to complete the installation.
Installing V.24 Dial-up Connection for USB
To install the V.24 dial-up connection for USB:
1. Select
Start > Settings > Control Panel.
2. Select
Network Connections.
3. Under new tasks, select
Create a new connection to open a New Connection
To enable some USB adaptors it may be necessary to connect the adaptor before
starting the computer.
