Chapter 3. Installation and Configuration Process
Vol. IV-3-8 Alcatel-Lucent
4. Installation: Licensing
5. Configuration: Information
6. Configuration: System Layout
9500 MXC Node 9500 MXC Terminal
Within 9500 MXC CT, select Installation > Licensing
to view the licensed capabilities for the Node.
If licensed capabilities are not exceeded, or will not be
exceeded for the planned node capacity, go to step 6.
If exceeded, the capabilities table displays a cross
against the offending RAC plug-in with details of the
mismatch.
Refer to Node License on page 4-2 for details.
Applies only to:
• The IDU ES for Ethernet throughputs above the base 50
Mbps license.
• The IDU 20x for DS rate capacities above the base
16xDS1. (For E rates, licensing does not apply; the base
rate of 40xE1 represents the maximum capacity)
Select
Installation > Licensing to view licensed
capabilities.
Refer to IDU ES License on page 4-3, or to IDU 20x
License on page 4-4.
9500 MXC Node 9500 MXC Terminal
Select Configuration > Information and enter data in
the user configurable fields for terminal and site name,
contact details and site grid.
Refer to Node and Terminal Information on page 6-1
for details.
Select Configuration > Information and enter data in the
user configurable fields for terminal and site name, contact
details and site grid.
Refer to Node and Terminal Information on page 6-1 for
details.
9500 MXC Node 9500 MXC Terminal
Select System Summary to check what plug-ins have
been installed in each IDC slot, and that the existing
plug-in configuration for the slot matches the plug-in
type installed.
A tab option is provided within each module to accept
or decline the plug-in type installed.
Refer to System Summary on page 15-2 for details.
System layout does not apply to the Terminal (layout is
fixed).
