7. Configuration: Plug-ins
8. Configuration: Protection
9. Configuration: Circuits
10. Configuration: Networking
9500 MXC Node 9500 MXC Terminal
Select Configuration > Plug-Ins to view settings for
the plug-in.
Edit, if required, using the settings specified in the
installation datapack. Remove the Tx Mute, if set.
Refer to Node and Terminal Plug-ins on page 7-1 for
details.
Select Configuration > Plug-Ins to view settings for the
Terminal modules.
Edit, if required, using the settings specified in the
installation datapack. Remove the Tx Mute, if set.
Refer to Node and Terminal Plug-ins on page 7-1 for
details.
9500 MXC Node 9500 MXC Terminal
Select Configuration > Protection to view and
configure protection settings.
Refer to Node Protection on page 8-1 for details.
Select Configuration > Protection to view and configure
protection settings.
Refer to Terminal Protection on page 8-17 for details.
9500 MXC Node 9500 MXC Terminal
Select Configuration > Circuits to view and set
circuit connections.
Refer to Circuits on page 9-1 for details.
PDH and SDH IDUs do not present a Circuits screen
option.
The IDU ES includes a Circuits screen - functionality for
its Ethernet and tributary modules is identical to the Node.
Select
Configuration > Circuits to view and set.
Refer to Circuits on page 9-1 for details.
9500 MXC Node 9500 MXC Terminal
Select Configuration > Networking to set IP
addressing and routing, and if required, trap
destinations.
Refer to Networking Configuration on page 10-1 for
details.
Select
Configuration > Networking to set IP addressing
and routing, and if required, trap destinations.
Refer to Networking Configuration on page 10-1 for
details.
