9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-7-7
4 Path settings window:
• Set Tx and Rx frequencies, Tx power.
• Provides an ATPC option.
• Indicates Tx power (measured).
The displayed Tx Frequency Range, Tx high or Tx low, and the choices of Tx/
Rx spacing are read from the installed ODU. Settings outside the allowable
ranges are not accepted.
5 Factory Tx Muted is an ex-factory default setting and appears above the Tx
Power line. Once removed it will not appear again.
6 Confirms the supported modem profile settings and the current setting for the
selected RAC. For the RAC 30 it confirms compatibility action and options
between RAC 30 versions, while for the RAC 40 it confirms and supports
compatibility options between software versions:
RAC 30
For the RAC 30 it is used to determine the current over-air compatibility status
supported by RAC 30 plug-ins.
Item Description
