Chapter 15. Diagnostics
Vol. IV-15-28 Alcatel-Lucent
Figure 15-9. Example Link Performance Screen
Item Description
1 Status Monitors provide a real time view of operational status/performance.
Data is updated at 2 second intervals. The cross polarization discrimination
entry only applies to RAC 40.
2 G.826 Monitors. Set with the Start, Stop and Clear tabs.
3 Click Export to save the data to your PC as a .csv file.
1
2
3
