Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 179

Chapter 8

Develop Control Applications

Elements of a

Control Application

A control application consists of several elements that require planning for

efficient application execution. Application elements include the following:

•Tasks

•Programs

• Routines

• Parameters and Local Tags

• Add-On Instructions

Topic Page

Elements of a Control Application 179

Tasks 181

Programs 186

Routines 188

Parameters and Local Tags 189

Programming Languages 190

Add-on Instructions 191

Extended Properties 192

Access the Module Object from an Add-On Instruction 193

Monitor Controller Status 194

Connection Overview 195

Controller Communication Interaction with Control Data 195

Produce and Consume (Interlock) Data 197

Send and Receive Messages 199

Monitor I/O Connections 200
