Preface
Additional Resources
The following documents contain additional information concerning related
products from Rockwell Automation.
Table 1 - Additional Resources
Resource Description
CompactLogix 5480 Controller
Specifications Technical Data,
publication
5069-TD002
Provides specifications for CompactLogix 5480 controllers.
CompactLogix 5480 Controllers
Installation Instructions, publication
5069-IN019
Describes how to install a CompactLogix 5480 controller.
CompactLogix System Selection
Guide, publication
1769-SG001
Provides information about how to design and select components for a
CompactLogix system.
Compact 5000 I/O Modules and
EtherNet/IP Adapters Specifications
Technical Data, publication
5069-
TD001
Provides specifications, wiring diagrams, and functional block diagrams for
Compact 5000™ I/O modules and EtherNet/IP adapters.
Replacement Guidelines: Logix 5000
Controllers Reference Manual,
publication
1756-RM100
Provides guidelines on how to replace the following:
• ControlLogix® 5560/5570 controller with a ControlLogix® 5580
controller
• CompactLogix 5370 L3 controllers with a CompactLogix 5480 controller
Compact 5000 Digital I/O Modules,
publication
5000-UM004
Provides information on how to install, configure, and operate Compact
5000 digital I/O modules.
Compact 5000 Analog I/O Modules
User Manual, publication
5000-
UM005
Provides information on how to install, configure, and operate Compact
5000 analog I/O modules.
Compact 5000 High-speed Counter
Module User Manual, publication
5000-UM006
Provides information on how to install, configure, and operate a
Compact 5000 high-speed counter modules.
EtherNet/IP Communication Modules
in Logix 5000 Control Systems User
Manual, publication
ENET-UM004
Describes how to use 5000 Series EtherNet/IP communication modules.
Ethernet Design Considerations
Reference Manual, publication
ENET-RM002
Describes the following Ethernet concepts:
• Overview
• Network layout and components
• Network infrastructure devices
• Network infrastructure features
•Protocol
EtherNet/IP Socket Interface
Application Technique, publication
ENET-AT002
Describes the socket interface that you can use to program MSG
instructions to communicate between a Logix 5000™ controller and
Ethernet devices that do not support the EtherNet/IP application protocol.
EtherNet/IP Embedded Switch
Technology Application Guide,
publication
ENET-AP005
Describes how to install, configure, and maintain linear and Device Level
Ring (DLR) networks by using Rockwell Automation® EtherNet/IP devices
that are equipped with embedded switch technology.
Integrated Architecture® and CIP Sync
Configuration Application Technique,
publication
IA-AT003
Provides information on CIP Sync™ and the IEEE 1588-2008 Precision Time
Protocol.
